PRODUCT MODEL:1030-404-0001
1.ELECTRICAL:
CURRENT RATING:1A
INSULATOR RESISTANCE:1000MΩ MIN
DIELECTRIC WITHSTANDING:AC 100V
2.OPERATING TEMP:20°C～+85°C
3.MATERIAL:
INSULATOR MATERIAL: PBT
CONTACT PLATED: SELECTOVE PLATING
SHELL: COPPER ALLOY AND STEEL
4.SHELL PLATED : NI PLATED
