- Mini PCI 124P 插槽 H15.5mm.引脚双贴
PRODUCT MODEL:5040-004-0002
1.MATERIAL SPECIFICATION
1-1.HOUSING: THERMOPLASTIC LCP UL94V-0. BLACK.
1-2.CONTACT: COPPER ALLOY C5210.
1-3.LATCH: STAINLESS STEEL SUS301, MATTE TIN PLATING OVER NICKEL.
2.PLATING SPECIFICATION
2-1.CONTACT AREA: GOLD FLASH(1u"min), ALL OVER NICKEL.
2-2.SOLDERING AREA: GOLD FLASH(1u"min) PLATING.
1.MATERIAL SPECIFICATION
1-1.HOUSING: THERMOPLASTIC LCP UL94V-0. BLACK.
1-2.CONTACT: COPPER ALLOY C5210.
1-3.LATCH: STAINLESS STEEL SUS301, MATTE TIN PLATING OVER NICKEL.
2.PLATING SPECIFICATION
2-1.CONTACT AREA: GOLD FLASH(1u"min), ALL OVER NICKEL.
2-2.SOLDERING AREA: GOLD FLASH(1u"min) PLATING.
